FEATURES:
Sound absorption: NRC 0.65~0.95 by authoritative organization.
Fire-resistant: Fire rating class as class A under ASTM-E 84,or class 1 under BS476.
Eco-friendly: Formaldehyde reach E1.
EASY INSTALL:
Width and length as per customized:
21 patterns for your choice
Name | Wooden art acoustic panel |
Structure | Base materials/finish/back |
Base materials | Standard/eco-friendly/fire-resistant/Moisture-prooffire-resistant |
Finish | Natural veneer/melamine/HPL fire-proof /PU painting |
Back | Black fire-resistant sound absorbing fleece/Soundtex sound absorbing fleece |
Model | WY-A01/03/04/06/11/14/19/20/21/22/24/25/28/29/31/32/33, WY-SPA/B/D/F |
Common size | W 600/1200mm*L 2400mm*T 12/15/18mm |
NRC | 0.65~0.95 |
Fire-resistant | class A under ASTM-E 84,or class 1 under BS476. |
Formaldehyde emission | 0.08 mg/m3 |
| Application | Office,Study space,hotel,hospital |
WY-33
WY-SPA
WY-SPB
WY-SPD
MDF SERIES
◕ WALL INSTALLATION SYSTEM
WOOD SLAT INSTALL METHOD
01、First install the wooden batten according to the design requirements and level it, install the acoustic panel on the wooden batten with gun nails, and insert the wooden slat into the sidegroove
02、Align the side groove of the second acoustic panel with the wooden slat, and install and fix it with gun nails
03、Align the side groove of the third acoustic panel with the wooden slat, and install and fix it with gunnails
04、Repeat until the installation is completed, the joints between the boards are generally recommended to be 3-5mm, and the nailing position is on the side of the panel
KEEL SYSTEMS INSTALLATION METHOD
01、Fix side keel WY-009 on the wood battens and light steel keel with gunnail and screws
02、Fix the WY-008 main keel at the two ends of installation area. It is recommended to keep 3-5mm gap during installation
03、Move the side groove along WY-008 and WY-009 direction from left to right and bottom to top
04、For solid wood and natural veneer, if the wood grain pattern is required, it must be numbered in advance and installed fromsmall to large
◕ WOOD CEILING SYSTEM
EXPOSED T GRID
- Easy to install
TEGULAR
- The panel edges can be painted in the same color as finish, and the keel can be painted in black or the same color as finish
CONCEALED T GRID
- Invisible keels, panel beveled edges, and the panel edges can be painted in the same color as finish
CUSTOM CEILING
FEATURES
• Variety of shape sizes • Acoustic performance • Fire-resistant
▼ Melamine finish: grain
▼ Melamine finish: pure
▼ Veneer finish
▼ UV Painting Finish: refer to Pantone color
◕ Acoustic
◕ Fire-resistant
◕ Formaldehyde Emission
ASTM E84-class A-15mm Wooden acoustic panel
BS476-7-class 1-15mm Wooden acoustic panel
EN717-1-class E1-wooden acoustic panel
Wooden pallet packaging
++
Delivery time and Production capacity:
Delivery time | 10 or 12 days for 1200sqm |
Production Capacity | 1000sqm per week |
Shipping& packing& payment terms:
Package | 1 or 2 pcs packed into one carton |
Pallet | 25 carton packed into one pallet |
20gp container | 385ctns/ |
Carton size/weight | 650*2450*100mm/ 35kg |
Pallet size/weight | 2450*650*1000mm/975kgs |
Payment | T/T ,50% deposit and 50% before shipment. |
Min. order | 100sqm. You can mix finish, The quantity of each finish must be a multiple of 9,like 9,18 pcs. |
